Study on Inhibitory Effect of Lipopeptides Produced by Bacillus subtilis Czk1 on Anthracnose and Powdery Mildewof Rubber Tree

doi:10.13304/j.nykjdb.2022.0129

Abstract

Abstract:

Powdery mildew and anthracnose are important diseases which affect the production of natural rubber. In order to identify the inhibitory effect of lipopeptides from Bacillus subtilis Czk1 on anthracnose and powdery mildew of rubber tree，rubber seedling Reyan 7-33-97 was used as material， the effects of the lipopeptide extraction of strain Czk1 on the mycelia growth morphology and conidial development of Colletotrichum gloeosporioides were studied by co-culture method. Vitro and pot experiments were carried out to evaluate the inhibitory effect on rubber tree anthracnose and powdery mildew. The results showed that Bacillus subtilis Czk1 lipopeptide could induce mycelial deformation and breakage of C. gloeosporioides. The minimum Czk1 lipopeptide concentration of inhibiting C. gloeosporioides was 40 mg·L^-1， and the EC₅₀ value of inhibiting condia germination of C. gloeosporioides was 3.80 mg·L^-1. When the Czk1 lipopeptide concentration was 40 mg·L^-1， the inhibition rate of condia germination of C. gloeosporioides was 68.84%. When the concentration of lipopeptide was 1 000 mg·L^-1， the incidence rate ofrubber tree anthracnose decreased 43.40% and 49.90%， the disease index of rubber tree powdery mildew decreased 32.60 and 21.60， and the inhibition effect of powdery mildew of rubber tree was 45.60%. The results showed that the lipopeptide of strain Czk1 could effectively reduce the incidence of anthracnose and powdery mildew， inhibit the growth of the pathogen and delay the expansion of the disease， which had good biocontrol potential to control the leaf diseases of rubber trees.

Key words: Bacillus subtilis, lipopeptide antibiotics, rubber tree anthracnose, rubber tree powdery mildew, inhibitory effects

摘要：

白粉病和炭疽病是影响天然橡胶生产的重要病害。为明确枯草芽孢杆菌（Bacillus subtilis ）Czk1脂肽物质对橡胶树炭疽病和白粉病的抑制作用，以橡胶种苗‘热研7-33-97’为试验材料，通过共培养法研究菌株Czk1脂肽粗提物对橡胶树炭疽病菌（Colletotrichum gloeosporioides）生长发育的影响，并采用脂肽粗提物和孢悬液法进行离体和盆栽试验评价其对橡胶树炭疽病和白粉病的抑制作用。结果表明，Czk1脂肽类粗提物可导致橡胶树炭疽病菌菌丝畸形和断裂，抑制病菌的最低质量浓度为40 mg·L^-1，抑制其分生孢子萌发EC₅₀值为3.80 mg·L^-1；40 mg·L^-1的Czk1脂肽类粗提物对橡胶树炭疽病菌孢子萌发抑制率达68.84%。脂肽粗提物质量浓度在1 000 mg·L^-1时，可使盆栽和离体试验中炭疽病发病率降低43.40%和49.90%，同时亦使白粉病病情指数降低32.60和21.60，对橡胶树白粉病的防治效果为45.60%。由此表明，菌株Czk1脂肽物质能有效降低橡胶树炭疽病和白粉病发病率、抑制病菌生长并延缓病情的扩展，具有防治橡胶树叶部病害的良好生防潜力。

关键词: 枯草芽孢杆菌, 脂肽类化合物, 橡胶树炭疽病, 橡胶树白粉病, 抑菌作用

CLC Number:

F767.5

Chunping HE, Lanyan FAN, He WU, Yanqiong LIANG, Weihuai WU, Rui LI, Fucong ZHENG. Study on Inhibitory Effect of Lipopeptides Produced by Bacillus subtilis Czk1 on Anthracnose and Powdery Mildewof Rubber Tree[J]. Journal of Agricultural Science and Technology, 2023, 25(6): 126-134.

贺春萍, 樊兰艳, 吴贺, 梁艳琼, 吴伟怀, 李锐, 郑服丛. 枯草芽孢杆菌Czk1脂肽物质对橡胶树炭疽病和白粉病的抑制效果研究[J]. 中国农业科技导报, 2023, 25(6): 126-134.

Figures/Tables 7

References 36

1	余卓桐,李学忠,罗大全,等. 橡胶树病害综合治理体系研究[J]. 中国热带农业, 2006(1): 27-30.
	YU Z T, LI X Z, LUO D Q, et al.. Study on integrated management system of rubber tree diseases [J]. China Trop. Agric., 2006(1): 27-30.
2	HAN J H, SHIM H, SHIN J H, et al.. Antagonistic activities of Bacillus spp. strains isolated from tidal flat sediment towards anthracnose pathogens Colletotrichum acutatum and C. gloeosporioides in South Korea [J]. Plant Pathol. J., 2015, 31(2):165-175.
3	CHEN D, LIU X, LI C Y, et al.. Isolation of Bacillus amyloliquefaciens S20 and its application in control of eggplant bacterial wilt [J]. J. Environ. Manage., 2014,137(4):120-127.
4	刘芳,薛鹏琦,乔俊卿,等. 西藏低温适生芽孢杆菌的分离鉴定及其抗菌和促生作用[J].中国生物防治, 2010, 26(4):453-460.
	LIU F, XUE P Q, QIAO J Q, et al.. Isolation and identification of a low-temperature-adapted Bacillus in Tibet and its antagonistic and growth-promoting effect [J]. Chin. J. Biol. Control, 2010, 26(4):453-460.
5	CAWOY H, DEBOIS D, FRANZIL L, et al.. Lipopeptides as main ingredients for inhibition of fungal phytopathogens by Bacillus subtilis/amyloliquefaciens [J]. Microb. Biotechnol., 2015, 8(2): 281-295.
6	ONGENA M, JACQUES P. Bacillus lipopeptides: versatile weapons for plant disease biocontrol [J]. Trends Microbiol., 2008, 16(3): 115-125.
7	STEIN T. Bacillus subtilis antibiotics: structures, syntheses and specific functions [J]. Mol. Microbiol., 2005, 56(4): 845-857.
8	BAIS H P, FALL R, VIVANCO J M. Biocontrol of Bacillus subtilis against infection of arabidopsis roots by Pseudomonas syringae is facil biofilm formation and surfactin production [J]. Plant Physiol., 2004, 134(1):307-319.
9	KEARNS D B, CHU F, RUDNER R, et al.. Genes governing swarming in Bacillus subtilis and evidence for a phase variation mechanism controlling surface motility [J]. Mol. Microbiol., 2004, 52(2): 357-369.
10	NIHORIMBERE V, CAWOY H, SEYER A, et al.. Impact of rhizosphere factors on cyclic lipopeptide signature from the plant beneficial strain Bacillus amyloliquefaciens S499 [J]. FEMS Microbiol. Ecol., 2012, 79(1):176-191.
11	黄有航,谭志琼,王寅寒,等. 一株橡胶树白粉病生防菌的鉴定及在橡胶树叶片定殖规律研究[J]. 植物保护, 2013,39(2):77-81.
	HUANG Y H, TAN Z Q, WANG Y H, et al.. Identification of a bacterial isolate for biocontrol of the rubber tree powdery mildew and its colonization in rubber tree leaves [J]. Plant Prot., 2013, 39(2):77-81.
12	时涛,彭建华,刘先宝,等. 橡胶树内生细菌多样性初探及拮抗菌株的筛选[J]. 中国森林病虫, 2011, 30(2):5-9.
	SHI T, PENG J H, LIU X B, et al.. Rubber endophytic bacteria population diversity and screening of antagonistic strains [J]. For. Pest Disease, 2011, 30(2):5-9.
13	秦云霞,涂敏,阳美芳,等. 8株木霉菌对橡胶树红根病的拮抗作用[J]. 热带农业科学,2015,35(3):41-45, 53.
	QIN Y X, TU M, YANG M F, et al.. Antagonistic effect of eight strains of trichoderma on Ganoderma pseudoferreum causing red root rot of rubber tree [J]. Chin. J. Trop. Agric., 2015,35(3):41-45, 53.
14	孙亮,刘文波,杨廷雅,等. Bacillus subtilis HAB-1在不同培养基上的形态观察及抑菌活性测定[J]. 广东农业科学, 2013,40(13):76-80
	SUN L, LIU W B, YANG T Y, et al.. Different medium of Bacillus subtilis HAB-1 of the morphological observation and antifungal activity [J]. Guangdong Agric. Sci., 2013,40(13):76-80.
15	赵璐璐,贺春萍,郑肖兰,等. 枯草芽孢杆菌Czk1菌株对橡胶树根病菌的抑制作用及对炭疽病生防效果研究初报[J]. 南方农业学报, 2011,42(7):740-743.
	ZHAO L L, HE C P, ZHENG X L, et al.. Effect of Bacillus subtilis strain Czk1 on different rubber root pathogens and in vitro control of Colletotrichum gloeosporioides on rubber leaf [J]. J. Southern Agric., 2011,42(7):740-743.
16	贺春萍,赵璐璐,孙亮,等. 一株产铁载体橡胶树拮抗细菌的分离鉴定及耐药性分析[J]. 热带作物学报, 2012, 33(12): 2240-2245.
	HE C P, ZHAO L L, SUN L, et al.. Identification and drug resistant analysis of a strain of siderophores producting antagonist bacteria from rubber tree [J]. Chin. J. Trop. Crops, 2012, 33(12): 2240-2245.
17	樊兰艳,贺春萍,梁艳琼,等. 橡胶树枯草芽孢杆菌Czk1抑菌活性物质的理化性质[J]. 热带生物学报, 2013, 4(1): 36-44, 55.
	FAN L Y, HE C P, LIANG Y Q, et al.. Characteristics of the antimicrobial active component of Bacillus subtilis strain Czk1 [J]. J. Trop. Biol., 2013, 4(1): 36-44, 55.
18	HE C P, FAN L Y, WU W H, et al.. Identification of lipopeptides produced by Bacillus subtilis Czk1 isolated from the aerial roots of rubber tree [J/OL]. Genet. Mol. Res., 2017, 16(1):16018710[2022-01-10]. .
19	梁艳琼,唐文,董文敏,等. 枯草芽孢杆菌菌株Czk1挥发性物质的抑菌活性及其组分分析[J]. 南方农业学报, 2019,50(11):2465-2474.
	LIANG Y Q, TANG W, DONG W M, et al.. Antifugal effect and components analysis of volatile organic compounds from Bacillus subtilis Czk1 [J]. J. Southern Agric., 2019,50(11):2465-2474 .
20	梁艳琼,李锐,吴伟怀,等. Bacillus subtilis Czk1挥发性化合物对橡胶树红根病菌的抑制作用[J]. 中国农业科技导报,2020,22(11):116-123.
	LIANG Y Q, LI R, WU W H, et al.. Inhibition of volatile organic compounds produced by Bacillus subtilis Czk1 on red root of rubber tree [J]. J. Agric. Sci. Technol., 2020,22(11):116-123.
21	郝捷,李杨,陈飞,等. 死谷芽孢杆菌对香菇栽培料中木霉菌的抑制研究[J]. 微生物学通报, 2013, 40(2): 228-235.
	HAO J, LI Y, CHEN F, et al.. Inhibitory of Bacillus vallismortis to Trichoderma parasitized in lentinus edodes [J]. Microbiol. China,2013,40(2):228-235.
22	许文耀. 普通植物病理学实验指导[M]. 北京:中国科学出版社, 2000:97-101.
23	BAIS H P, FALL R, VIVANCO J M. Biocontrol of Bacillus subtilis against infection of Arabidopsis roots by Pseudomonas syringae is facilitated by biofilm formation and surfactin production [J]. Plant Physiol., 2004,134(1): 307-319.
24	唐文,梁艳琼,许沛冬,等. 枯草芽孢杆菌Czk1诱导橡胶树抗病性相关防御酶系研究[J]. 南方农业学报, 2016,47(4):576-582.
	TANG W, LIANG Y Q, XU P D, et al.. Induction of resistance-related defensive enzymes in hevea brasiliensis by Bacillus subtilis Czk1 [J]. J. Southern Agric., 2016,47(4):576-582.
25	CHEN X H, KOUMOUTSI A, SCHOLZ R, et al.. Comparative analysis of the complete genome sequence of the plant growth promoting bacterium Bacillus amyloliquefaciens FZB42 [J]. Nat. Biotechnol., 2007,25(9):1007-1014.
26	WANG Y, WANG J, QUAN C, et al.. Purification and antifungal characterization of an antifungal substance from Bacillus amyloliquifaciens [J]. China Biotechnol., 2007, 27(12): 41-45.
27	陈莉,缪卫国,刘海洋,等. 短短芽孢杆菌A57菌株对棉花主要病原真菌的拮抗作用及其最佳液体发酵条件[J]. 中国生物防治学报, 2007, 23(): 22-27.
	CHEN L, MIAO W G, LIU H Y, et al.. Antagonistic action of Brevibacillus brevs A57 against cotton mainly pathogenic fungus and its fermentation condition with the strongest antagonistic activity [J]. Chin. J. Biol. Control., 2007, 23(S1): 22-27.
28	候美玲,辛媛媛,郝志敏,等.玉米内生芽胞杆菌的抗菌活性物质及其拮抗玉米大斑病菌机理的初步研究[J]. 农业生物技术学报,2012,20(9): 1018-1027.
	HOU M L, XIN Y Y, HAO Z M, et al.. Antifungal activity substance of endogeny Bacillus in maize (Zea mays) and mechanisms against Setosphaeria turcica [J]. J. Agric. Biotechnol., 2012, 20(9): 1018-1027.
29	张涛,李雪艳,杨红梅,等. 4株拮抗细菌对棉花黄萎病的防治效果及机制[J]. 中国生物防治学报, 2018,34(6):882-889.
	ZHANG T, LI X Y, YANG H M, et al.. Biocontrol effect and mechanism of four strains of antagonistic bacteria against cotton verticillium wilt [J]. Chin. J. Biol. Control,2018,34(6):882-889.
30	王宝,杨杨,蔡吉苗,等. 内生解淀粉芽胞杆菌BEB33脂肽类化合物分析及对香蕉枯萎病菌拮抗作用研究[J]. 中国生物防治学报,2019,35(5):785-792.
	WANG B, YANG Y, CAI J M, et al.. Identification of lipopeptides of endophytic Bacillus amyloliquefaciens BEB33 and antifunal activity against Fusarium oxysporum f. sp. Cubense [J]. Chin. J. Biol. Control., 2019,35(5):785-792.
31	王雅. 枯草芽孢杆菌菌株Bv10胞外抗菌物质的纯化及其特性测定[D]. 南宁:广西大学,2013.
	WANG Y. Purification and characterization of antimicrobal substances produced by Bacillus subtilis strain Bv10 [D]. Nanning: Guangxi University, 2013.
32	杨丽莉,吕凤霞,别小妹,等. 枯草芽孢杆菌抗菌脂肽对嗜水气单胞菌抑菌效果[J]. 食品科学,2011,32(1): 193-198.
	YANG L L, LYU F X, BIE X M, et al.. Study on the anti-Aeromonas hydrophila effect in vitro of lipopeptide from Bacillus subtilis fmbJ [J]. Food Sci., 2011, 32(1): 193-198.
33	罗楚平,刘邮洲,吴荷芳,等. 脂肽类化合物bacillomycin L抗真菌活性及其对水稻病害的防治[J]. 中国生物防治学报, 2011,27(1):76-81.
	LUO C P, LIU Y Z, WU H F, et al.. Antifungal activity and rice disease biocontrol performance of lipopeptide antibiotic bacillomycin L [J]. Chin. J. Biol. Control, 2011,27(1):76-81.
34	高振峰,赵佳. 贝莱斯芽孢杆菌 ZSY-1 脂肽物质对番茄采后软化及早疫病发生的影响[J]. 西北农业学报, 2022, 31(1):2-10.
	GAO Z F, ZHAO J. Effect of lipopeptide by Bacillus velezensis ZSY-1 on tomato postharvest softening and early blight [J]. Acta Agric. Bor-Occid. Sin., 2022, 31(1):2-10.
35	李明通,孟凡强,周立邦,等. 生姜根腐病的病原菌鉴定及抗菌脂肽的防治效果[J]. 南京农业大学学报, 2020,43(6):1134-1142.
	LI M T, MENG F Q, ZHOU L B, et al.. Identification of the pathogen of ginger root rot and the control effeciency of antifungal lipopeptides [J]. J. Nanjing Agric. Univ., 2020,43(6):1134-1142.
36	陈梅春,邓英杰,陈燕萍,等. 芽胞杆菌FJAT-2349脂肽对枇杷采后炭疽病菌抑制作用[J]. 福建农业学报 2021,36(12):1478-1483.
	CHEN M C, DENG Y J, CHEN Y P, et al.. Inhibitory effect of lipopeptide secreted by Bacillus Strain FJAT-2349 against anthracnose pathogen [J]. Fujian J. Agric. Sci., 2021,36(12):1478-1483.

处理 Treatment		孢子萌发率 Spore germination rate/%	抑制率 Inhibition rate/%
Czk1	60 mg·L^-1	20.43±4.33 c	71.37
	40 mg·L^-1	22.23±5.13 c	68.84
	20 mg·L^-1	25.32±4.93 bc	64.51
	10 mg·L^-1	30.47±6.06 b	57.30
CK1		71.35±4.50 a	—
甲醇 Methanol		75.13±4.41 a	—

处理 Treatment		孢子萌发率 Spore germination rate/%	抑制率 Inhibition rate/%
Czk1	60 mg·L^-1	20.43±4.33 c	71.37
	40 mg·L^-1	22.23±5.13 c	68.84
	20 mg·L^-1	25.32±4.93 bc	64.51
	10 mg·L^-1	30.47±6.06 b	57.30
CK1		71.35±4.50 a	—
甲醇 Methanol		75.13±4.41 a	—

处理 Treatment	平均病斑大小 Average lesion size/（cm×cm）	发病率 Incidence/%
10 mg·L^-1脂肽物+RC178 10 mg·L^-1 lipopeptide+RC178	（1.33×1.08） b	90.00
100 mg·L^-1脂肽物+RC178 100 mg·L^-1 lipopeptide+RC178	（0.98×0.78） c	79.80
1 000 mg·L^-1脂肽物+RC178 1 000 mg·L^-1 lipopeptide+RC178	（0.80×0.71） c	46.70
CK2	—	—
RC178	（1.65×1.40） a	96.60
甲醇+RC178 Methanol+RC178	（1.66×1.31） a	95.00

处理 Treatment	平均病斑大小 Average lesion size/（cm×cm）	发病率 Incidence/%
10 mg·L^-1脂肽物+RC178 10 mg·L^-1 lipopeptide+RC178	（1.33×1.08） b	90.00
100 mg·L^-1脂肽物+RC178 100 mg·L^-1 lipopeptide+RC178	（0.98×0.78） c	79.80
1 000 mg·L^-1脂肽物+RC178 1 000 mg·L^-1 lipopeptide+RC178	（0.80×0.71） c	46.70
CK2	—	—
RC178	（1.65×1.40） a	96.60
甲醇+RC178 Methanol+RC178	（1.66×1.31） a	95.00

处理 Treatment	平均病斑大小 Average lesion size/（cm×cm）	发病率 Incidence/%
CK3	—	—
RC178	（0.87×0.75） a	95.20
甲醇+RC178 Methanol+RC178	（0.90×0.74） a	96.30
1 000 mg·L^-1脂肽物 1 000 mg·L^-1 lipopeptide	（0.59×0.49） b	51.80
